High Pressure Pumps - S...-SS series

single acting
single air drive head
Pressures to 3.700 bar (53.660 psi)
stainless steel body and wetted parts

General Information

S…-SS pumps

single acting
single air drive head
Pressures to 3.700 bar (53.660 psi
stainless steel body and wetted parts

MAXIMATOR pumps S…-SS series are available as single acting with single air drive head.

S…-SS pumps are single acting types with single air drive head. They are compact and lightweight for simple installation in both static and portable applications. They will operate at an air pressure as low as 1 bar (14.5 psi) due to minimal internal friction. S pumps are ideal for applications demanding fast response time

Stainless steel bodies and plungers and polyurethane seals.
Pumps come standard with side inlet only
Ideal for portable power packs
For air drive pressure from 1 bar (14.5 psi) to10 bar (145 psi) maximum.

Overview

Type	i^*	Displacement volume	Displacement volume	P max.^*	P max.^*	Flow	Flow
		cm³	in³	bar	psi	cfm	l/min
S40-SS	1:39	12,00	0,76	390	5650	0,14	4,00
S80-SS	1:80	6,00	0,37	800	11600	0,07	2,00
S160-SS	1:160	3,00	0,18	1630	23635	0,04	1,00
S200-SS	1:200	2,00	0,15	1930	28000	0,03	0,80
S250-SS	1:244	2,00	0,12	2400	34800	0,02	0,60
S350-SS	1:370	1,00	0,08	3700	53660	0,02	0,45
